| Parameter | Characteristic | 30kW CCS Single Gun |
|---|---|---|
| Input Power | Rated Power Input voltage | 30 kW 415 Vac (±10%), 50 Hz Three phase |
| Output Power | Number of Output Output current Output Charging Outlet Output voltage Power Factor Efficiency | 1 60A Max CCS-2 150-1000V DC ≥0.98 ≥0.95 |
| User Interface and Controls | Display Push Button User Authentication | 7'' TFT LCD with touch Emergency Stop RFID + OCPPv1.6 |
| Environment | Ambient Temperature Storage Temperature Altitude Humidity | -20⁰C to 55⁰C -40⁰C to 70⁰C <2000 Mtr <95%, Non condensing |
| Communication | External Metering and Billing Charging Operation | WiFi, RS485, LAN/4G + OCPPv1.6 Available RFID Card/ Scan QR Code/Mobile App |
| Protection | Input/ Output protection Mechanical Protection Cooling | Over/Under voltage protection, Overload protection, Short circuit protection, Current leakage protection Grounding protection, Surge protection, Over/Under temperature IP54 Forced Air Cooling |
| Regulation | As per Safety Mounting | IEC 61851-1:2017 , IEC 61851-21-2 CE Wall / Pole Mount |
